Antelope Audio Zen Tour Synergy Core PROMO Bundle w. Free Edge Solo

Description

Specifications

Antelope Audio Zen Tour Synergy Core 1x Antelope Audio Zen Tour Synergy Core
The mighty Antelope Audio Zen Tour desktop audio interface is made even more potent by the four DSP and two FPGA processors tucked up inside. These beasts can process even more effects so that your computer doesn’t have to!

Product features
19 inchesno
Number of analogue Inputs 8
Number of analogue outputs 8
Computer connectors USB, Thunderbolt 3 (USB C)
Deals forproducers, everyone
Digital inputs S/PDIF, ADAT
Digital outputs S/PDIF, ADAT
Phantom power yes
Suitable for operating system Apple OSX / Mac OS, Microsoft Windows
Headphone output yes
Input(s) with Hi-Z yes
Maximum sample rate 192 kHz
Included data cable USB cable
Included software none
Number of microphone inputs 4
MIDI I/O (din connector)none
Software included yes, download
Power adapterungrounded flat Europlug
Weight and dimensions including packaging
Weight (incl. packaging)3.3 kg
Dimensions (incl. packaging)30.0 x 22.5 x 17.0 cm
Product specifications
Thunderbolt 3 and USB 2.0 Audio Interface
analogue inputs:
4x instruments/line (TRS)
4x microphone/line (TRS/XLR combo jack)
analogue inputs:
8x line (DB25)
2x monitor (TRS jacks)
2x headphone (TRS)
2x ‘transformer based’ re-amp outputs (TRS jack)
all line outputs are ‘DC-coupled’ and support CV apllications
digital:
ADAT: 44.1/48kHz – 8 inputs / 8 outputs
88.2/96kHz – 4 inputs / 4 outputs
176.4/192kHz – 2 inputs / 2 outputs
S/PDIF:
44.1 to 192 kHz – 2 inputs / 2 outputs
USB: USB-B 2.0
Thunderbolt 3: type C port (up to 32 channels)
microphone preamps:
EIN: -128dBu
dynamic range: 121dB
THD: -106dB
maximum input: -20dBu
maximum gain: 75dB
A/D-conversion:
124dB DNR
-110 THD+N
D/A-conversion:
127dB DNR
-100 THD+N
D/A monitor converter:
130dB DNR
-115 THD+N
sample rates (kHz):
44.1, 48, 88.2, 176.4, 192kHz
clocking:
4th generation Acoustically Focused Clocking & Jitter Management
64-bit DDS

Antelope Audio Edge Solo 1x Antelope Audio Edge Solo
Antelope Audio’s Edge Solo is a modelling microphone with a single capsule. It features Antelope Audio’s own modelling technology that gives you stunningly-accurate emulations of a number of classic and renowned microphone models.
Product features
Tube microphoneno
Microphone sensitivity (dBV/PA)-35
Microphone impedance50-99 ohms
Low-cut filterno
Maximum SPLnot specified
Maximum frequency20 – 20.9 kHz
Microphone accessoriescase
Minimum frequency20 – 21 Hz
Pad switchno
Polar patterncardioid
Stereono
Weight and dimensions including packaging
Weight (incl. packaging)1.4 kg
Dimensions (incl. packaging)31.5 x 17.5 x 9.5 cm
Product specifications
Antelope Edge Solo
modelling microphone
diaphragm diameter: 34 mm
power supply: 48V DC phantom power
output connector: 3-pin XLR, male
colour: matt black
available microphone models via FPGA AFX:
Berlin 47 FT
Berlin 49T
Berlin 57
Berlin 87
Berlin 67
Berlin M103
Vienna 12
Vienna 414
Tokyo 800T
Oxford 4038
Sacramento 121R
weight: 0.32 kg
included: compact case
